  • #13852
    davefortey
    Participant

    Hello All,
    I appear to have an intermittent fault with the engine panel (bottom of steering pedestal) on my B32. although the ignition and switches work fine, the low oil pressure warning occasionally sounds and the lights dont always operate when turning off or on. I have heard it could be a problem with the internal connection block??? however this is extremely sensitive to touch and expensive, no surprise there!
    any tips or thoughts??

    rgds dave

    #13853
    bobclements
    Keymaster

    Hi Dave

    Don’t know the answer, but things I have found I will share.

    1./ 99% of all electrical problems come down to bad contact in the connectors. Undo all the connectors behind the panel, and at the engine relay box, clean them all, spray them with switch cleaner, and put them back together.

    2./ The Volvo panel has a number of diodes in there, so it’s not just a case of simple lights in there.However, this is all potted, so I doubt any water has got in there. It could be the ignition barrel (connections again), so give it a good spray with switch cleaner, and see if that cures it.

    You can get switch cleaner from RS components. While you’re at it, get a tin of IPA (Isoprpol Alchohol), which is also excellent for cleaning and degreasing, and a tin of PTFE spray (which is excellent for lubricating stuff).
